Choose the Future. Now.
A unique solution for heating, cooling and hot water production with assured performance all year round.
Maxa’s i-290 heat pumps are designed to generate extremely high water temperatures even in the harshest conditions with a maximum flow temperature of 78°C.
The i-290 range is available in 9 sizes with power outputs between 6kW and 27kW in heating mode. The i-290 range can be used with new builds and retro installations and can be combined to work with all emitter types.
The R290 technology enables operation without the use of any fuel gas, ensuring efficient and sustainable operation without any CO2 emissions into the environment.
Product Type :
Market :
Application :
Downloads
Datasheets
Manuals
Technical Bulletins
Sales Collateral
Model Range
| Model | SKU | Nom. Output kW | Phase | SCOP @ 35°C | SCOP @ 45°C | SCOP @ 55°C | SCOP @ 65°C | Max Flow Temp (°C) | Refrigerant | Dimensions (W x D x H) | RRP | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | Gamma i-290 6kW | I290_0106 | 4.64kW | Single | 4.42 | 3.86 | 3.23 | 2.98 | 75 | R290 | 1105 x 490 x 870 | £7,820.00 |
| Gamma i-290 9kW | I290_0109 | 7.93kW | Single | 4.57 | 4.13 | 3.79 | 3.24 | 75 | R290 | 1105 x 490 x 870 | £8,464.00 |
 | Gamma i-290 12kW | I290_0112 | 9.02kW | Single | 4.48 | 3.89 | 3.38 | 3.04 | 75 | R290 | 1105 x 490 x 1440 | £10,580.00 |
| Gamma i-290 15kW | I290_0115 | 12.81kW | Three | 4.6 | 4.04 | 3.58 | 3.28 | 75 | R290 | 1105 x 490 x 1440 | £11,780.00 |
| Gamma i-290 18kW | I290_0118 | 13.21kW | Three | 4.52 | 3.97 | 3.53 | 3.2 | 75 | R290 | 1105 x 490 x 1440 | £12,445.00 |
 | Gamma i-290 21kW | I290_0121 | 18.4kW | Three | 4.72 | 4.07 | 3.6 | 3.15 | 78 | R290 | 1600 x 680 x 1315 | £19,000.00 |
| Gamma i-290 23kW | I290_0123 | 20.1kW | Three | 4.58 | 4.01 | 3.58 | 3.15 | 78 | R290 | 1600 x 680 x 1315 | £19,285.00 |
| Gamma i-290 25kW | I290_0125 | 21.8kW | Three | 4.3 | 3.82 | 3.56 | 3.11 | 78 | R290 | 1600 x 680 x 1315 | £20,615.00 |
| Gamma i-290 27kW | I290_0127 | 23.2kW | Three | 4.33 | 3.84 | 3.48 | 3.05 | 78 | R290 | 1600 x 680 x 1315 | £20,995.00 |
